6ES7901-3DB30-0XA0 6ES7901-3DB30-0XA0 S7-200 PLC Cable USB RS 485 for USB/PPI multimaster advanced PPI ,HAVE IN STOCK

$0.00 $59.95

Quantity

6ES7901-3DB30-0XA0 support PPI,multimaster PPI,advanced PPI, S7-200PLC and HMI TP177/OP177 6ES7 901-3DB30-0XA0 90 degree.

Made by us,100% tested before the shipment,quality is guaranteed,1 year warranty.

Package:

1pc 6ES7901-3DB30-0XA0

Features:

1.optoelectronic isolated adapter, built-in 8 DIP switches, support PPI protocol,multi-master PPI protocol, advanced PPI protocol, and 187.5Kbps high speed communication

2.support 10/11 bit MODEM communication,built-in DC24V high efficiency power module, and DC5V-5V isolated power supply module,achieve the PPI, advanced PPI high-speed communication, 100% compatible with Simatic original

3.PPI interface built-in multi-protections, anti-static, 600W surging protection, overvoltage protection, overcurrent protection, then downloading and monitoring is more stable.

4.Support Simatic S7-200 full range of PLC programming, uploading and downloading, and support Simatic text and touch screen application, OS updating, such as TP177 / OP177 / Smart 700/1000 HMI etc.

How to use:

Ordinary USB / PPI mode

For direct connection with your PC

◇ set the PPI / Freeport mode (switch 5 = 0)

◇ set the baud rate (switch 1,2,3)

◇ Set the local mode (switch 6 = 0)

◇ Set 11bits (switch 7 = 0)

For connection with Modem

◇ set the PPI / Freeport mode (switch 5 = 0)

◇ set the baud rate (switch 1,2,3)

◇ set a remote mode (switch 6 = 1)

◇ set 10 or 11bits (switch 7),the bit of each character setting matches with your Modem

Multi-master PPI mode

When the cable is applicable to multi-master mode, no need to set the baud rate switch, STEP7-Micro / WIN software will automatically start to find the baud rate of your CPU, set as follows:

Setting PPI mode (switch 5 = 1)

Setting local mode (switch 6 = 0)

All of our cable are made by us and comes with the drivers and install procedures or can be downloaded from our support page on our website
