Kinco MT4720TE 15" TFT 1024*768 HMI SCREEN PANEL ,HAVE IN STOCK,FASTING SHIPPING

Kinco MT4720TE 15" TFT 1024*768 HMI SCREEN PANEL ,HAVE IN STOCK,FASTING SHIPPING

$0.00 $885.95



Kinco MT4720TE 15" TFT HMI SCREEN PANEL
HAVE IN STOCK,FASTING SHIPPING
MT4720TE


Performance specification



Display 15" TFT
Resolution 1024*768
Color 65536
Backlight LED
Brightness 250cd/m2
Backlight life 50000 hours
Touch Panel 4-wire precision resistance network
Processor 32-bit 800MHz RISC
Memory 128M FLASH + 64M DDR2
Expandable memory 1 USB Host, 1 SD Card
Recipe memory & RTC 512KB + RTC
Printer port USB Host/Slave/Serial port
Ethernet Support
Program download USB /Serial port/Ethernet port
COM port COM0:PLC RS232/PLC RS485-2/4, COM1:PLC RS232/PLC RS485-2/4, COM2:PC/PLC RS232


Electrical specification



Isolated power supply Built-in
Rated power 13W
Rated voltage DC24V
Input range DC21V~DC28V
Power down allowe <3ms
Insulation resistance Greater than 50MΩ@ 500V DC
Dielectric strength test 500V AC 1 minute


Environment specification



Operating temperature -10～60℃
Operating humidity 10～90% non-condensing
Storage temperature -20～70℃
Storage humidity 10～90% non-condensing
Shockproof test 10～25Hz (X, Y, Z direction, 2G, 30 minutes)
Cooling method Natural air cooling

Structure specification



Shell color Silver
Shell material aluminium alloy
Dimensions(mm) 406.5×313.5×56.8mm
Cutout size(mm) 388×295mm
Weight 4.5 Kg



Dimensions (Unit:mm)



MT4720TE,draft
