| 3 channels of 14 bits precision current input, 4 channels of PT100 temperature input and 2 channels 10 bits precision voltage output
3 channels of current,0~20mA and 4~20mA are optional; 2 channels of voltage, 0~5V and 0~10V are optional. They can be set by host machine.
Platinum resistance input, PT100
3 channels A/D and 4 channels PT input with PID adjust function.
Can be set as special function module for XC series PLC, up to 7 modules can be connected. XC-E3AD4PT2DA-H: isolated for analog and digital part General specifications Item | Analog current input（AD） | Temperature input （PT） | Analog voltage output（DA） | | Analog input | DC0~20mA、4~20mA | PT100 | - | | Range of temperature detect | - | -100~350℃ | - | | Max output range | DC0~40mA | - | - | | Range of analog output | - | - | DC0~5V、0~10V （External load resistance 2KΩ~1MΩ） | | Range of digital input | - | - | 10 bits（0~1023） | | Range of digital output | 14 bits（0~16383） | -1000~3500 | - | | Resolution | 1/16383(14Bit); Converted data are stored in PLC(14Bit) in hex form | 0.1℃ | 1/1023(10Bit); Converted data are stored in PLC in hex form（10Bit） | | PID output value | 0~K4095 | - | | Integrated accuracy | 0.8% | ±0.5℃ | 0.8% | | Convert speed | 20ms/1 channel | 3ms/1 channel | | Power for analog | DC24V±10%,100mA | | Installation | Fixed with M3 strews or directly installed in DIN46277(35mm width) guide rail | | External dimension | 63mm×102mm×73.3mm | |
