Xinje XC1-32R-E PLC CONTROLLER MODULE ,
have in stock, fast shipping
Product description
5 DI/5 DO, 5 relay outputs (R) or transistor outputs transistor (AC220V or DC24V power supply; without expansion module, without BD board or clock;
support power-off retentive; support basic logic control and data operation.
General Speicifications:
Item | Specification |
| Insulation Voltage | Above DC 500V 2MΩ |
| Noise Resistance | 1000V 1uS pulse for 1 minute |
| Environment Temperature | 0℃~60℃ |
| Ambient Humidity | 5%~95% |
| COM 1 | RS-232, be connected to host machine or HMI for programming or debugging |
| COM 2 | - |
| Installation | M3 screw fixed or DIN46277 (35mm width) guide rail installation |
| Grounding | The third type grounding (Never perform common grounding with strong power system) |
Performance specifications:
| Item | Specification |
| Program Operation Mode | Circulation scanning mode, timing scanning mode |
| Program Mode | Instructions and ladder chart |
| Dispose Speed | 0.5us |
| Power Failure Holding | FlashROM |
| User Program’s Capacity | 32K |
| I/O Points | 5 input points，5 output points |
| Output Format | Relay/transistor |
| Power Supply | E: AC220V C: DC24V |
| Interior Coil’s Points (M) | 576 points |
| Timer（T） | Points | 80 points |
| Specification | 100mS timer：set time 0.1~3276.7 seconds
10mS timer：set time 0.01~327.67 seconds
1mS timer：set time 0.001~32.767 seconds |
| Counter（C） | Points | 48 Points |
| Specification | 16 bits counter:：Set value K0~32767
32 bits counter：Set value K0~2147483647 |
| Data Register（D） | 406 characters |
| FlashROM Register（FD） | 510 characters |
| High-speed Count Format | - |
| Timing Scanning Interval Setting | - |
| Password Protection | 6 characters ASCII |
| Self-diagnose Function | Power on self-diagnose, monitor timer, grammar check |
Dimension (unit: mm)
We will tested this package before shipping !!!
